Insulating tie rods

2025-09-11

Xrun Outdoor Epoxy Resin System comes with a complete range of specifications and models. It possesses pollution resistance, moisture resistance, salt spray resistance, superior mechanical and electrical properties, high crack resistance, and ultra-low temperature resistance（-65°C), etc.

Product model &ratio Tg Characteristics Application Process Applications
HE-5079/HH-5079/X13=100/90/350 105-120 Low viscosity, UV resistance, and filthy resistance Vacuum casting、APG Outdoor insulators
HE-5072/HH-5072/X13=100/80/320 70-80 Low viscosity, UV resistance, filthy resistance, and very good crack resistance Vacuum casting、APG Outdoorinsulators, CT&PT
E-5078A/HE-5078B/X13=100/100/350 90-105 Low viscosity, UV resistance, filthy resistance, and good crack resistance Vacuum casting、APG Outdoor insulators
HE-5272/HH-5272/13=100/100/300 60-70 Low viscosity, UV resistance, filthy resistance, and excellent crack resistance Vacuum casting、APG Outdoor insulators, CT& PT, embedded poles
HW-5078A/HW-5078B=100/100 95-110 Prefilled, UV-resistant, filthy resistance, and excellent crack resistance Vacuum casting、AP Outdoor insulators, CT& PT, embedded poles
HW-5075A/HW-5075B=100/100 120-135 Prefilled, UV-resistant, filthy resistance, excellent crack resistance Vacuum casting、APG Outdoor insulators, embedded poles
HW-5080A/HW-5080B=100/100 100-120 Prefilled, UV-resistant, filthy resistance, and excellent crack resistance Vacuum casting、APG Outdoor insulators, embedded poles
HW-5076A/HW-5076B=100/100 130-145 Prefilled, UV-resistant, filthy resistance, and excellent crack resistance Vacuum casting、APG Outdoor insulators, embedded poles
HW-5180A/HW-5180B=100/100 110-125 prefilled, UV resistance,fithy resistance, excellent crack resistance Vacuum casting、APG Outdoorinsulators, embedded poles
